SMART LED PANEL 600x600mm
2.145.000₫
- Wireless connection: Bluetooth Mesh
- Remote control via Internet (Using App Lumi Life).
- Control via indoor LAN (Using App Lumi Life).
- Dimming: 0% -> 100%
- Changing light color temperature: 2700K -> 6500K.
- Controlling by groups of Lighting, HCL, Lighting scenes, Rule, Scenes, Calendar (Customizable according to user needs).
- Can control the device by voice through the integration of Google Assistant, Alexa.
- Direct control via Remote scene via Bluetooth Mesh network mechanism (No need through HC)
- Lifespan: 25,000 hours
SMART PANEL LED
Smart Panel LED is a type of LED lighting with a square or rectangular plate design that is used to install ceiling or drop ceilings. Not only for lighting in the family, LED Panels are also popular in office buildings, hospitals, schools…
Using LED lighting technology, Lumi Smart Panel LEDs produce stable, non-flickering lighting and help save energy. Moreover, with the IoT ingester built in, smart LED Panels also offers intelligent control experiences that go beyond the usual lighting needs.
Applications of Smart Panel Light
Besides lighting in the home space, Lumi Smart Panel LEDs are also especially suitable for schools, offices, hospitals. With the characteristics of a fairly large floor lighting area and the need for even lighting, smart LED Panel panels are a very suitable choice. 600 & 600 LED panels create light that fills every corner of the space in the classroom, office, hospital. Using LED lighting technology, the lighting from LED Panel lights is extremely stable, without flickering to help protect the eyes of students and office workers when sitting at school, working in the LED space all day. Not only that, applying human-centered lighting technology, LED Panel lights are also designed with “HCL – Human Centric Lighting” mode to create a bio-light environment that stimulates the secretion of hormones working and resting status at the right time.
As a result, students and office workers can experience a healthy light environment, increase productivity, work and study. In particular, the flexible light treatment changes in color temperature and light intensity also very well support for patients with medical problems such as anxiety disorders, sleep disturbances, depression,…
Advantages of Smart panel LED Light
- Allowturning on/ off / timer lights with Smartphone and voice
- Usea Bluetooth Mesh wireless connection, which makes it easy for homeowners to control lights or light clusters without being affected by electrical infrastructure
- Applicationof Human Centric Lighting (HCL) to improve circadian rhythm
- Lamplife lasts up to 25000 hours of lighting, equivalent to more than 10 years (average lighting 6h / day)
- Honestlight to the human eye with CRI color > 80
- Easilycombine with other Lumi smart devices to create utility living scenarios
Product Overview
Product code: LM-PL40W/S60-1B
- Wireless connection: Bluetooth Mesh.
- Remote control via the Internet (Using the Lumi Life App).
- Control via in-house LAN (Using the Lumi Life App
- Dimming: 0% -> 100%
- Change light color temperature: 2700K -> 6500K.
- Group control Lighting, HCL, Scene Lighting, Rule, Scene, Calendar (Customized according to user needs).
- It is possible to control the device by voice through the integration of Google Assistant, Alexa.
- Control directly through remote scenes through the Bluetooth Mesh network mechanism (No need via HC).
Optical specifications
| Color Completion Index | 80 |
| White / warm temperature | Trắng/ấm (2700K -> 6500K) |
| Photoethetrosy | 3900 lm – 6000K (Trắng) & 3700 lm – 3000K (Vàng) |
| Lighting efficienc | 98 lm/W – 6000K (Trắng) & 93 lm/W – 3000K (Vàng) |
Specifications
| Operating voltage | 170 – 240V AC ~ 50Hz |
| Power consumption | 40W |
| Communication | Bluetooth Mesh |
| Power play | 10 dbm |
| Limited distance between Bluetooth devices | 10m/40m (Khi có vật cản/không có vật cản) |
| Lamp life | 25.000 giờ |
| Ceiling hole | 600x600mm |
Install device controls
Allow devices to join the network
-
-
-
- To install device control using the app on the user’s phone a new HC (home controller) central controller is required, version 2020 and above (Bluetooth Mesh core hardware supported) and home created on the system.
- Users who sign in to the Lumi Life app => select settings => select device settings => select HC=> Bluetooth=> for the device joining the network.
-
-
- Observe the state of the lamp, if the light flashes 2 times in a row for 2 seconds, then the yellow light means that it has successfully joined the network.
- If the device does not join the network, the device may have been configured, the user resets the device to return to network join mode.
Control your device on the Lumi Life app
After the device successfully joins the network, we can control the basic functions (adjust the color temperature, increase the brightness or turn on / off) above App Lumi Life.
Warm, white light console on Lumi Life App
Reset device
In case the device has been configured to the network before, after re-powering, the light will re-light up the previously configured state, at this point, if we want to configure the device to join another network, it is necessary to reset the device. To reset the device, we take the following steps:
- Power/disconnect the device 5 times in a row, the interval between each status switch from Off -> On for about 5 seconds, then we’ll see the lights flashing three times.
- Within 8 seconds immediately after the flashing light, we proceed to turn off the power and power the lamp again to confirm the Reset device. After successful reset, the light will flash and turn white.
After the light flashes 3 times – within 8 seconds we turn it off / on again
NOTE: Assuming the device that joined HC’s Bluetooth Mesh network is then turned off by the Lumi Life App, however due to an issue that causes HC to not work, at the moment we cannot turn the device back on via App Lumi Life, the customer can perform the device power off / back action twice (the time between Off -> Turn on the device is about 5 -> 10 seconds) to turn on the device.
Smart Lighting System
1.023.000₫
- Length: 5m
- Operating voltage: 24V
- Capacity 18W / m
- Number of possible colors: 16 million colors
- Communication: Bluetooth Mesh
- Lifespan: 25,000 hours
The device was launched in November 2020 with the addition of bluetooth mesh module ( while maintaining the same features as the Zigbee version), it is possible to simultaneously control both Lumi's bluetooth and Zigbee devices simultaneously.
Watch now
- Design: compact with plastic case and scratch resistant tempered glass.
- Have devices join the Zigbee network link devices in the same system together.
- For Smart Lighting devices and Bluetooth modules join HC's Bluetooth Mesh network to link devices in the same system together.
- Control devices using the Lumi Life app.
- Perform automatic processing of settings: scene, rule, device timer, device group.
- Warranty: 24 months
2.145.000₫ – 2.585.000₫
Help control the brightness of the lights change the potentiometer
Watch now
- Color: Black/White
- Shape: Rectangle/Square
- Liner champagne/gold Liner
- Media: ZigBee
- Designed using capacitive touch technology
- Scratch-resistant tempered glass
- Remote control via internet/indoor LAN (Via Lumi Life app)
- Device voice control via Google integration Assistant, Alexa, Apple Siri
- Safe, explosion-proof
- Warranty: 24 months
- Glass: Flat/Concave
- Border type: Curved edge/Diamond edge
- Color: Champagne rim /Gold rim
1.485.000₫
- Wireless connection: Bluetooth Mesh.
- Remote control via Internet (Using App Lumi Life).
- Control via indoor LAN (Using App Lumi Life).
- Changing the light intensity (Dimming) for 24V DC monochrome Led strip lights: 0% -> 100% (3 output ports support 3 dimming Led strip lights)
- Changing the light color temperature for Led String Lights WW (CCT): 2700K -> 6500K. (2 output ports support 1 WW light wire control).
- Control group Lighting, HCL, Lighting scene, Rule, Scene, Calendar (Customizable according to user needs).
- Can control the device by voice through the integration of Google Assistant, Alexa.
- Control directly via Remote scene via Bluetooth Mesh network mechanism (No need through HC).
- 24 months warranty
1.650.000₫
- Wireless connection: Zigbee/ Bluetooth
- Motion detection.
- Measure the light intensity of your surroundings.
- Measure the temperature and humidity level of the surroundings.
- Regularly update your device's battery level to the Lumi Life App
- The sensitivity/latency of the sensor can be changed.
- The components of the sensor can serve as inputs for Rule (Customized according to user needs).
- Direct control with on/off switch types, In Out module (Zigbee version) through advanced feature installation (Binding).
- Warranty: 24-month
990.000₫
- On/off control for electrical devices output (Supports 2 inputs and 2 outputs). The outputs connect and control electrical devices and the inputs can be configured as trigger signals for Rule / Scenes / Calendar.
- Wireless connection: Zigbee
- Remote control via Internet (Using App Lumi Life)
- Control via indoor LAN (Using App Lumi Life)
- Direct grouping mechanism with devices of the same type in Zigbee network
- 24 months warranty
The device was launched in November 2020 with the addition of bluetooth mesh module ( while maintaining the same features as the Zigbee version), it is possible to simultaneously control both Lumi's bluetooth and Zigbee devices simultaneously.
Watch now
- Design: compact with plastic case and scratch resistant tempered glass.
- Have devices join the Zigbee network link devices in the same system together.
- For Smart Lighting devices and Bluetooth modules join HC's Bluetooth Mesh network to link devices in the same system together.
- Control devices using the Lumi Life app.
- Perform automatic processing of settings: scene, rule, device timer, device group.
- Warranty: 24 months
- Length: 5m
- Operating voltage: 24V DC
- Capacity: 18W / m
- Color temperature: Yellow - White (2700K - 6000K)
- Communication: Bluetooth Mesh
- CRI color rendering index: 90
- Lifespan: 25,000 hours
1.045.000₫
- Chiều dài: 5m
- Điện áp hoạt động: 24V DC
- Công suất: 18W/m
- Nhiệt độ màu: Vàng - Trắng (2700K - 6000K)
- Truyền thông: Bluetooth Mesh
- Chỉ số hoàn màu CRI: 90
- Tuổi thọ: 25.000 giờ
- Wireless connection: Bluetooth Mesh
- Remote control via Internet (Using App Lumi Life).
- Control via indoor LAN (Using App Lumi Life).
- Dimming: 0% -> 100%
- Changing light color temperature: 2700K -> 6500K.
- Controlling by groups of Lighting, HCL, Lighting scenes, Rule, Scenes, Calendar (Customizable according to user needs).
- Can control the device by voice through the integration of Google Assistant, Alexa.
- Direct control via Remote scene via Bluetooth Mesh network mechanism (No need through HC)
- Lifespan: 25,000 hours
572.000₫ – 748.000₫
- CRI color rendering index: 90
- Lifespan: 25,000 hours
- Wireless connection: Bluetooth Mesh.
- Remote control via Internet (Using App Lumi Life).
- Control via indoor LAN (Using App Lumi Life).
- Dimming: 0% -> 100%
- Change light color temperature: 2700K -> 5700K.
- Controlling by groups of Lighting, HCL, Lighting scenes, Rule, Scenes, Calendar (Customizable according to user needs).
- Can control the device by voice through the integration of Google Assistant, Alexa.
- Control directly via Remote scene via Bluetooth Mesh network mechanism (No need through HC).
968.000₫ – 1.276.000₫
- CRI color rendering index: 90
- Lifespan: 25,000 hours
- 3 types of projection angle: 15 °, 24 °, 36 °
- Wireless connection: Bluetooth Mesh.
- Remote control via Internet (Using App Lumi Life).
- Control via indoor LAN (Using App Lumi Life).
- Dimming: 0% -> 100%
- Change light color temperature: 2700K -> 5700K.
- Controlling by groups of Lighting, HCL, Lighting scenes, Rule, Scenes, Calendar (Customizable according to user needs).
- Can control the device by voice through the integration of Google Assistant, Alexa.
- Control directly via Remote scene via Bluetooth Mesh network mechanism (No need through HC).
2.420.000₫ – 2.585.000₫
TECHNICAL INFORMATION:
- Operating voltage: 80 - 270V ~ 50 - 60Hz
- No-load power consumption: <0.5W
- Operating temperature: 0 ° C - 50 ° C
Load capacity:
Load resistance: 700W
LED capacity: 150W
Network: Zigbee HA 1.2
Size:
Square: 95 x 95 x 31.5mm
Rectangle: 121.5 x 80 x 33.2mm
Watch now
1.705.000₫ – 1.870.000₫
A smart touch switch that uses capacitive touch technology, Zigbee wireless, tempered glass, scratch-resistant, combined with the surrounding LED shine circle to create sophistication, elegance
Made in Viet Nam
Voltage: 150 - 250 VAC
- Operating temperature: 0 - 40ºC max
- Power: 700w (Incandescent lamp) -150w (LED) / 1 button
- Size: Square (95 x 95 mm) - Rectangle (121.5 x 80 mm)
Watch now
1.540.000₫
Luxurious and distinctive design: The motion sensor is made of PP flame-retardant plastic, with an exquisite design with luxurious, white rounded lines to create the modernity of the product. The eye icons are highly interactive.
Sensor plastic cover:
- Optimal eye angle:
+ Identification angle of 72 ° -92 °
+ Identification angle 30 ° -102 ° or 30 ° - 92 °
+ Identification angle 46 ° -102 ° or 51 ° - 92 °
Watch now
2.420.000₫ – 2.585.000₫
The stair light switch integrated with sensor is an intelligent indoor device for automatic lighting based on human presence and light intensity. With the design using capacitive touch technology and scratch-resistant tempered glass, the device will make your home look more stylish and modern than ever.
TECHNICAL INFORMATION:
- Operating voltage: 100-240V ~ 50-60Hz
- No-load power consumption: <0.5W
- Operating temperature: 0 C - 50 C
- Load capacity: Incandescent lamp: 500W and Led: 150W
- Network: Zigbee /No Zigbee
- Measurements: Rectangular version: 80 x 121,5 x 31,5 mm and Square version: 95 x 95 x 31,5 mm
Watch now
It can detect illegal intrusion, then activate a system of devices such as alerts, vortex lights, curtains, lights ... and send warning to phones or tablets. The sensor uses Zigbee wireless network with high security 802.15.4. On the other hand, the motion detection sensor is built into the environment sensor to measure information such as temperature, humidity, light ... to help create a fresh space, ensure the best living environment for your family.
TECHNICAL INFORMATION
- Operating voltage: CR2477 Battery - 3V 1000mA
- Operating temperature: 0 ° C - 50 ° C
- Operating humidity: 0 - 95%
- Battery life: 1 year
- Light measurement range: 0 - 10,000 lux
- Network: Zigbee HA 1.2
Watch now
1.650.000₫
Environmental sensors act as a "doctor" who measures the temperature, light, humidity and so on in your house besides automatically turning on/off lights when movement is detected. In addition, the sensor is also integrated into security solutions, hence, activates alerts, turns on the lights ... when noticing illegal intrusion
Operating voltage: 100 - 20V ~ 50 - 60Hz
- No-load power consumption: <0.5W
- Operating temperature: 0 ° C - 50 ° C
- Operating humidity: 0 - 95%
- Light measurement range: 0 - 10,000 lux
- Maximum recognition angle: 102 °
- Network: Zigbee HA 1.2
Watch now
